 Can GQ-4X erease M35080,V,V6 Chip?
 New Topic  Reply to Topic
 Printer Friendly
Author Previous Topic Topic Next Topic

Marin

USA
29 Posts

Posted - 09/07/2012 :  10:49:46  Show Profile  Reply with Quote
Is it possible with GQ-4X erase M35080, V, or V6 ?

Thanks.
Reply #1

Marin

USA
29 Posts

Posted - 09/12/2012 :  16:37:25  Show Profile  Reply with Quote
Anyone???
Go to Top of Page
Reply #2

ZLM

2923 Posts

Posted - 09/16/2012 :  11:14:57  Show Profile  Reply with Quote
This chip is in the supported list.
You can just select it from the software.
Go to Top of Page
Reply #3

Marin

USA
29 Posts

Posted - 09/16/2012 :  13:53:01  Show Profile  Reply with Quote
I know you can read/ write this chipwith GQ-4X. I see that in device menu.
This chip is very specific and not every programer has function to erase this chip.This chip needs to be erase before you want to write it or it has to be new to be able to write it.

My question is can it be erase with GQ-4X?

Edited by - Marin on 09/16/2012 13:53:40
Go to Top of Page
Reply #4

ZLM

2923 Posts

Posted - 09/16/2012 :  22:37:11  Show Profile  Reply with Quote
sure. It can be read/erase/write on GQ-4X with ADP-088
Go to Top of Page
Reply #5

Marin

USA
29 Posts

Posted - 09/20/2012 :  20:58:46  Show Profile  Reply with Quote
Thank you.
Go to Top of Page
Reply #6

Marin

USA
29 Posts

Posted - 09/22/2012 :  13:11:39  Show Profile  Reply with Quote
Just to let you know that GQ-4X does not work on this chip at all.
I have new chip.
It does not read correct, I read chip and all FFFFFFF.First 32 bytes needs to be all "0"s.
it does not erase it at all, and does not write correct.
This chip has special functions to be erase and GQ-4X does not support:
When you erase this chip it needs to be in delivery state.
Delivery State:
The first 32 bytes (incremental registers) are set to all "0"s, 16 words at $0000 The EEPROM memory array $0020-$3FFF set to all $FF. The Status register set to $10


Go to Top of Page
Reply #7

ZLM

2923 Posts

Posted - 09/27/2012 :  07:15:38  Show Profile  Reply with Quote
This chip I have it and tested works. Can you send us a testing chip? we can find it out why. Are you using ADP-088? make sure your connection are correct.
Go to Top of Page
Reply #8

Marin

USA
29 Posts

Posted - 10/04/2012 :  18:13:53  Show Profile  Reply with Quote
I have use ADP-88 and connections are OK .You can not erase chip. This is a main thing on this chip.Programer does not support it.
Every time you try to erase this chip ,
it pops window and says:
"Function not supported on this device or chip do not need to be erase"

Also I try to read chip that has info in it and all FFFFFFFF.

Edited by - Marin on 10/04/2012 18:25:36
Go to Top of Page
Reply #9

Marin

USA
29 Posts

Posted - 11/27/2012 :  22:08:45  Show Profile  Reply with Quote
I have picture but I can not post it.
I upload it but it shown nop picture.
I try put it form flicket but it is blocking http file
How do you post picture here?

Edited by - Marin on 11/27/2012 22:27:33
Go to Top of Page
Reply #10

hugos31

Peru
1 Posts

Posted - 12/15/2012 :  07:24:53  Show Profile  Reply with Quote
marin ,,please post your results on digital kaos

Arequipa
Go to Top of Page
Reply #11

ZLM

2923 Posts

Posted - 12/15/2012 :  09:08:33  Show Profile  Reply with Quote
When posting pictures, remove all special chars in file name, keep the file name as short as posible. It accepts only .jpg, .bmp, .png formats images. If you uploaded successfully but no picture displayed, then you can just leave it there, it will be fixed automatically later on.
Go to Top of Page
Reply #12

Marin

USA
29 Posts

Posted - 01/01/2013 :  15:28:36  Show Profile  Reply with Quote
Here is picture.
You can see that first 32 bytes are FF instead being 00.
Also Erase failed. This is New chip.


Image Insert:

147.62 KB

Edited by - Marin on 01/01/2013 15:33:56
Go to Top of Page
Reply #13

ZLM

2923 Posts

Posted - 01/05/2013 :  11:05:17  Show Profile  Reply with Quote
Make sure you have a correct connection.

Pin connection see: www.mcumall.com/support/***ADP-088_Connection.html

Remove the *** in above link.

Also, try
1. slower speed.
2. another chip
Go to Top of Page
Reply #14

joox777

Latvia
1 Posts

Posted - 05/04/2013 :  07:04:09  Show Profile  Reply with Quote
I try to write on new 35080 vp, v6 eeproms, and this programmer doesn't support it!!!
Just can read it and thats it!
Don't waste your time trying to do it with this programmmer, i spent on it more than month, no results!!!

Image Insert:

180.62 KB
Go to Top of Page
Reply #15

ZLM

2923 Posts

Posted - 05/28/2013 :  23:30:38  Show Profile  Reply with Quote
anyone can send a new chip for testing? this chip should be supported.
Go to Top of Page
Reply #16

jc179

25 Posts

Posted - 09/12/2014 :  05:45:10  Show Profile  Reply with Quote
Any update on this? ZLM didn you ever get a new chip to test with?
Go to Top of Page
Reply #17

medln25

Morocco
7 Posts

Posted - 10/10/2014 :  00:00:06  Show Profile  Reply with Quote
the top bytes of this chip cannot accept lower values than what it contains. a used chip cannot be reprogrammed if some bytes contains values higher than what you want to write on them.
in the image uploaded by joox777 he tried to change 0x3c by 0x28 (lower value) so the write has failed.
you have to use a new empty chip
Go to Top of Page
Reply #18

ZLM

2923 Posts

Posted - 06/08/2015 :  22:18:52  Show Profile  Reply with Quote
The GQ-4X is confirmed to be able to program those chips.

See:

http://www.mcumall.com/forum/topic.asp?TOPIC_ID=6134
Go to Top of Page
Reply #19

chiper

United Kingdom
2 Posts

Posted - 03/02/2016 :  02:09:02  Show Profile  Reply with Quote
I cannot erase chip but can read and right. I cannot modify or change the first 32 bytes. Should it be possible to erase. Thanks
Go to Top of Page
Reply #20

anniel

1996 Posts

Posted - 03/02/2016 :  08:20:12  Show Profile  Reply with Quote
Look at reply #17.
Go to Top of Page
Reply #21

ZLM

2923 Posts

Posted - 03/02/2016 :  22:16:18  Show Profile  Reply with Quote
Thanks anniel. This chip first 32 bytes can not be erased. You need an new chip.

Please note:
The latest version GQ-4x4 does not need remapping the connection. The regular SOIC8 adapter ADP-004 works fine. The older version GQ-4X need ADP-088 for remapping the pin connection.
Go to Top of Page
Reply #22

chiper

United Kingdom
2 Posts

Posted - 03/06/2016 :  07:29:11  Show Profile  Reply with Quote
Ok got it, thanks for the reply :)
Go to Top of Page
Reply #23

martininkent

United Kingdom
6 Posts

Posted - 01/01/2017 :  16:03:33  Show Profile  Reply with Quote
I can read my M35080, all ok, but it will not erase,,,, any advice
Go to Top of Page
Reply #24

martininkent

United Kingdom
6 Posts

Posted - 01/01/2017 :  16:30:43  Show Profile  Reply with Quote
quote:
Originally posted by martininkent

I can read my M35080-v6, all ok, but it will not erase,,,, any advice

Go to Top of Page
Reply #25

anniel

1996 Posts

Posted - 01/02/2017 :  05:34:18  Show Profile  Reply with Quote
Read this thread.
